2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage
2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage - Image 2
2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage - Image 3
2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage - Image 4
2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage - Image 5

2 YEARS WARRANTY LAB MASTER/MALAYSIA Precision Vacuum Drying Oven for Laboratory & Industrial Usage

WARRANTY: 2 YEARS AGAINST MANUFACTURING DEFECT!

DRYING, BAKING, WAX & HEAT TREATMENT EXPERT

Product Characteristics

  • Horizontal air circulates by double air ducts with high efficiency and high uniformity
  • PID controller with over-temperature protection function
  • Consists of fan switch, LED digital display and high temperature blast motor
  • New anti-hot handle
  • LCD temperature controller with SSR to ensure safety is upheld
  • Adjustable 4 gears speed fan for different requirements
  • Overheat temperature protection system
  • Independent temperature limiter
SKU: N/A Categories: , , Tags: , , , , , , , , ,

Description

Heating Mode Four walls heat conduction and decompression
Temperature Range RT +10-250°C
Useful Vacuum Degree Range <133Pa
Temperature Resolution Ratio 0.1°C
Temperature Motion ±1°C
Heating-Up Time DZ-1BIV = 80 minutes                                                    DZ-2BIV = 100 minutes                                        DZ-3BIV = 120 minutes
Inner Chamber High-quality stainless-steel sheet
Outer Shell Cold rolling steel electrostatic spraying exterior
Insulation Layer Aluminium silicate fibre
Heater Stainless steel electric heating tube
Observation Window Bullet proof glass with acrylic exterior protection
Nozzle Diameter 10mm
Temp. Control Mode Two Temperature Section with single shelf independent temperature control
Temp. Setting Model Touch Button Setting
Safety Device Overtemperature temperature sound-light alarm
Timer 0-9999 min (consists of timing wait function)
Operation Function Fixed Temperature Operation, Timing Function, Auto Stop
Additional Function Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking and power off parameter memory
Temp. Sensor PT100
Number of Shelf 2
Load per rack 15kg
Shelf (Accessory) 2
Shelf frame (Accessory) 4
Optional Accessories Silica Gel Connecting Pipe, Vacuum Pump

Additional information

Weight N/A
Dimensions N/A
Model

LM-DZ-1BIV, LM-DZ-2BIV, LM-DZ-3BIV
